Projektbeschreibung
Automatische Biegemaschine für Stahlstangen
Produktdetails:
| Herkunftsort: | Zhengzhou,China |
|---|---|
| Markenname: | SINCOLA |
| Zertifizierung: | ISO,CE,SGS |
| Modell-Nr: | SH4-8B |
Zahlung & Versandbedingungen:
| Mindestbestellmenge: | 1Sätze |
|---|---|
| Preis: | USD7000-20000 |
| Verpackungsinformationen: | Standard-Holzverpackung ODER Nacktpaket im 20-Fuß-Container |
| Lieferzeit: | 1Tage |
| Zahlungsbedingungen: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Lieferfähigkeit: | 1sets 5day |
| Modell | SH4-8B | Single Wire Steel bar diameter: | 4-10mm |
|---|---|---|---|
| Double Wire Steel bar diameter: | 4-8mm | Max Bending Angle: | 180° |
| Max pulling speed: | 120m/min | Max Bending Speed: | 1000°sec |
PRODUKTLISTE
| Modell | SH4-8B | SH4-8C | SH4-10B | SH4-10C |
| Single Wire Steel bar diameter | 4-10mm | 4-10mm | 4-12mm | 4-12mm |
| Double Wire Steel bar diameter | 4-8mm | 4-8mm | 4-10mm | 4-10mm |
| Max Bending Angle | 180° | 180° | 180° | 180° |
| Max pulling speed | 120m/min | 120m/min | 120m/min | 120m/min |
| Max Bending Speed | 1000°sec | 1000°sec | 1000°sec | 1000°sec |
| Length Accuracy | ±2mm | ±2mm | ±2mm | ±2mm |
| Angie Accuracy | ±2° | ±2° | ±2° | ±2° |
| Power | 15.2kw | 18.7kw | 20kw | 29kw |
| Processing shape | 500 kinds | 500 kinds | 500 kinds | 500 kinds |
| Gewicht | 1550kg | 1850kg | 1980kg | 2400kg |
| Abmessungen | 3200*1100*1700mm | 3400*1300*1750mm | 3200*1100*1800mm | 3400*1300*1850mm |
automatic-steel-bar-bending-machine
automatische Stahlbiegemaschine
automatische Stahlbiegemaschine
automatische Stahlbiegemaschine
automatische Stahlbiegemaschine
automatische Stahlbiegemaschine
automatische Stahlbiegemaschine
automatische Stahlbiegemaschine
automatische Stahlbiegemaschine
automatic-steel-bar-bending-machine
Automatic steel bending machine
This automatic steel bar bending machine adopts servo controlling system;
Automatically accomplish the functions of rebar’s feeding, straighten, bending and cutting etc.;
Max bending diameter of rebar is 12mm;
Continuously bend various stirrup of plane figure;
Widely used in construction industry and rebar manufacturing enterprise;
High efficiency and accurate processing precision.
Features of automatic steel bar bending machine
automatic steel bending machine1.Automatic wire feeding system ( CNC ).
2.Large storage capacity can save 500 processing geometric graphics, high degree automation
3.Automatic double wire intake system, high processing efficiency
4.High power feeding motor to ensure bending bar accuracy.
5.The intelligent fault identification alarm system maintenance more convenient
6.Aerodynamic design observation door, easy adjustment and maintenance, and more security and fast.
7.Heavy-duty design line planes, equipped with a brake and buffer device can prevent chaotic lines caused by downtime
8.High quality special material and high treatment to make straightening wheels, traction wheels, the metering wheel, longer life with lower operating costs
9.Touch-screen console, easy to operate, and more fast
