SKC40 Concrete Spraying System Concrete Shotcrete Machine
Product Details:
| Place of Origin: | Zhengzhou,China |
|---|---|
| Brand Name: | SINCOLA |
| Certification: | ISO,CE,SGS |
| Model Number: | SKC |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1sets |
|---|---|
| Price: | USD33-49 |
| Packaging Details: | Nude Package in 40ft container |
| Delivery Time: | 25days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 1sets 30day |
| Arm stroke | 4.5m/3.5+2 | Rated output | 40 m3/h |
|---|---|---|---|
| Spray horizontal distance | 2×11 | Spray vertical distance | 14m |
| Aggregate size | 15 or 25mm | Diesel engine power | 170kW |
PRODUCTS LIST
| SKC40A | SKC40B | |||
| Dimensions | LxWxH | mm | 9900x2290x2950 | 9900x2290x3700 |
| Weight | Net Weight | kg | 21,500 | 25,000 |
| Boom | Boom structure | Main arm rotate,
telescope |
Main arm rotate,
spray arm fold, telescope |
|
| Spray vertical distance | m | 14 | 20 | |
| Spray horizontal distance | m | 2×11 | 2×17 | |
| Arm stroke | m | 4.5 | 3.5+2 | |
| Concrete pump | Rated output | m3/h | 40 | |
| Aggregate size | mm | 15 or 25 | ||
| Drive | Drive mode | diesel | ||
| Diesel engine power | kW | 170 | ||
| Fuel tank capacity | L | 120 | ||
| Electric motor power | kW | 52 | ||
| Compressor | Air compressor power | kW | 55 | |
| Air output | m3/min | 10.7 | ||
| Max air pressure | Mpa | 0.7 | ||
| Additive system | System pressure | Mpa | 1.6 | |
| System outlet | L/h | 10-600 | ||
| Coagulant tank capacity | L | 1000 | ||
Working Principle of SKC40 Concrete Spray System
The SINCOLA – SKC40 concrete spray system is equipped with an automatic system for high precision synchronization between concrete pump and the additive dosing unit, thereby assuring spraying accuracy and quality. All the machine functions are available via the remote control, which facillitates the operator’s work.
Features Of SKC40 Concrete Spraying System
The system has a modular design, and can fit a large verity of applications.
The system consists of a diesel hydrostatic driven carrier and a spraying boom.
The chassis is designed to work in the toughest conditions in line with the requirements of mines, tunnels and outdoor construction. The six wheel drive increase its perfect manoeuvrability in difficult driving situations.
